LDPE Hdpe Plastic Twin Screw Extruder PVC PE Corrugated Pipe Making Machine

chất lượng tốt Dây chuyền đùn ống nhựa giảm giá
chất lượng tốt Dây chuyền đùn ống nhựa giảm giá
This machine is very good , and the after-saes service is good. The pvc board machine is easy to operate and the output is stable

—— Nancy

The pvc board extrusion machine is good quality , it is beautiful and the output is stable , this is a reliable company

—— Albert

Tôi trò chuyện trực tuyến bây giờ

LDPE Hdpe Plastic Twin Screw Extruder PVC PE Corrugated Pipe Making Machine

Trung Quốc LDPE Hdpe Plastic Twin Screw Extruder PVC PE Corrugated Pipe Making Machine nhà cung cấp
LDPE Hdpe Plastic Twin Screw Extruder PVC PE Corrugated Pipe Making Machine nhà cung cấp LDPE Hdpe Plastic Twin Screw Extruder PVC PE Corrugated Pipe Making Machine nhà cung cấp LDPE Hdpe Plastic Twin Screw Extruder PVC PE Corrugated Pipe Making Machine nhà cung cấp

Hình ảnh lớn :  LDPE Hdpe Plastic Twin Screw Extruder PVC PE Corrugated Pipe Making Machine

Thông tin chi tiết sản phẩm:

Place of Origin: ShanDong China
Hàng hiệu: AORUI
Chứng nhận: CE & ISO9001
Model Number: SJSZ80/156

Thanh toán:

Minimum Order Quantity: 1 set
Giá bán: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 30 sets per quarter
Contact Now
Chi tiết sản phẩm
Model Number: SJSZ80/156 Condition: New
Certificate: CE ISO9001 Nitrided layer thickness: 0.4-0.7mm
Screw Number: Two Hàng hiệu: Aorui
Motor: Siemens

LDPE Hdpe Plastic Single Wall Corrugated Pipe Production Line , PVC PE Corrugated Pipe Making Machine





Quick detail:



The extrusion line is newly developed based on European technique of new type pipe production line.


-It’s suitable for PE , PP and other polyolefine pipes high-speed extrusion.

-The extrusion line has many advantages, such as, nest outline , highly automatic control . stable performance.

-It’s greatly reputed by the customers due to “European performance and domestic.

-TURUI-series high-efficiency single screw extrude has 8 standard sizes ; 30. 45. 65.75. 90,105. 120. 150MM,and the L/D ratio is 30; 1D-37; 1D Effective length.




Description:



1. The shrinkable PP PE PVC single wall corrugated pipe production line is self-developed on the basis of original single wall corrugated pipe machine. The machine can produce pipes on a continuous manner with automatic shrink and automatic cutting.





2. Compared with blowing molding technology, the corrugated pipe making machine has high production speed, high continuity, easy operation and can promote the production efficiency and save labor cost. The final product is widely used in lavatory pipe, medical pipe etc.



3. The line shall be used to produce small diameter single wall corrugation pipe in PVC,PP and PE raw material. Molding corrugation pipe with smooth inside and outside surface,and even ripple at one time by corresponding die;


4. Used as wire and cable passing pipe ,washing machine drain pipe,dust collector pipe and ventiduct;
Small size corrugation pipe of 4-6.7 are used in car.







Specifications:



Model Pipe Diameter (mm) Motor Power Speed (m/min) Max .Output (kg/h) Total Power
SJ-45/30 5-15 15 1-20 45 35
SJ-50/30 16-32 18.5 1-15 90 55
SJ-65/30 40-63 37 1-10 120 70









Equipment warranty
1. About the equipment, Middle tech promised the good quality of 12 month.
2. during the warranty, no purposely and artificially damage change the damaged part, we will free
maintenance and technical services.
3. Over 12 months, Buyer's needs to pay the producing cost of the worn part, and life-long supply the part of equipment and freely device
