Conical Twin Screw Wood Plastic Composite Extrusion Machine For Wall Panel

chất lượng tốt Dây chuyền đùn ống nhựa giảm giá
chất lượng tốt Dây chuyền đùn ống nhựa giảm giá
This machine is very good , and the after-saes service is good. The pvc board machine is easy to operate and the output is stable

—— Nancy

The pvc board extrusion machine is good quality , it is beautiful and the output is stable , this is a reliable company

—— Albert

Tôi trò chuyện trực tuyến bây giờ

Conical Twin Screw Wood Plastic Composite Extrusion Machine For Wall Panel

Trung Quốc Conical Twin Screw Wood Plastic Composite Extrusion Machine For Wall Panel nhà cung cấp
Conical Twin Screw Wood Plastic Composite Extrusion Machine For Wall Panel nhà cung cấp Conical Twin Screw Wood Plastic Composite Extrusion Machine For Wall Panel nhà cung cấp Conical Twin Screw Wood Plastic Composite Extrusion Machine For Wall Panel nhà cung cấp

Hình ảnh lớn :  Conical Twin Screw Wood Plastic Composite Extrusion Machine For Wall Panel

Thông tin chi tiết sản phẩm:

Place of Origin: ShanDong China
Hàng hiệu: AORUI
Chứng nhận: CE UL CSA ISO9001
Model Number: SJSZ80/156

Thanh toán:

Minimum Order Quantity: 1 set
Giá bán: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per quarter
Contact Now
Chi tiết sản phẩm
Power: 55kw Screw&Barrel material: 38Cr MOAIA
Chứng nhận: CE ISO9001 Type of extruder: Twin screw
Temperature control: Omron Model Number: SJSZ80/156
Port: Qingdao Frequency control: ABB

WPC PVC Window Profile Production Line / WPC PVC Profile Machine For Wall Panel





Quick detail:



1. The wood-plastic is a new kind of synthetic material which uses PVC,PP,PE resin or recycled plastic and plant fibre ( wood powder,chaff,straw etc.) as raw material and through the process of mixing,exrusion,calibrating,drawing off and cutting.



2. This production line adopts international technology, uses PE, PP, PVC, PS or other plastics compounding with nature fiber powder as the raw material, employs high efficiency conical twin screw extruder ,mould .vacuum calibration table ,tractor and cutter.







Description:



1. This conical twin screw extruder is qualified for upvc,pvc,wpc powder extrusion directly to produce various kinds of plastic profile. full set of mould can safisfy different kinds of flooring ,profile ,decking ,panel and other wpc products. wpc product is very widely used nowadays! automatic length accounting device for precise cutting. cutting machine ,adopt advanced Germany technology. stainless steel and pneumatic controlled.



2. This machine can use one step extrusion method and also it can use the two-step extrusion method alter pelletizing. The two-step extrusion method can save the poer and space ,and the two-step extrusion method features the machine can gain the high outpue and stable extrusion pressure.



3. A pre-heating feeder is mounted on the top of the extruder which extraxts the humidity from the wood powder , so that the feeding section of the extruder can be filled with enough material and the plastification effect will be better. Special and well designed screw enables the raw material to be evently stay in the extruder. The screws and barrel are bi-metallic treated , more wearable and anti-corrosion.







Applications:



WPC decking application:
ourdoor application: wpc hollow decking, wpc solid decking, WPC beam/joist/keel, wpc wall cladding panel, wpc bench/chair, wpc fence/railing, upright post/pillar, wpc pavilion, wpc roof profiles, etc.
Indoor application: door window profiles, furniture decorative profiles, foaming profiles, etc.





Specifications:



Model YF180 YF240 YF300 YF400 YF500 YF600
Max. width of product(mm) 180 240 300 400 500 600
Extruder model SJSZ55/110 SJSZ65/132 SJSZ65/132 SJSZ65/132 SJSZ80/156 SJZ80/156
Max. extrusion capacity(kg/h) 150 250 250 250 360 360
Extruder power(kw) 22 30/37 30/37 30/37 55 55
Cooling water(M3/h) 5 7 7 8 10 12
Compressed air(M3/min) 0.2 0.3 0.3 0.3 0.4 0.5







Competitive Advantage:



1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.



Conical Twin Screw Wood Plastic Composite Extrusion Machine For Wall Panel
