China Sale PE Plastic Pipe Production Line Single Screw Extruder PVC / PP / PE Pipe Extrusion Machine

chất lượng tốt Dây chuyền đùn ống nhựa giảm giá
chất lượng tốt Dây chuyền đùn ống nhựa giảm giá
This machine is very good , and the after-saes service is good. The pvc board machine is easy to operate and the output is stable

—— Nancy

The pvc board extrusion machine is good quality , it is beautiful and the output is stable , this is a reliable company

—— Albert

Tôi trò chuyện trực tuyến bây giờ

China Sale PE Plastic Pipe Production Line Single Screw Extruder PVC / PP / PE Pipe Extrusion Machine

Trung Quốc China Sale PE Plastic Pipe Production Line Single Screw Extruder PVC / PP / PE Pipe Extrusion Machine nhà cung cấp
China Sale PE Plastic Pipe Production Line Single Screw Extruder PVC / PP / PE Pipe Extrusion Machine nhà cung cấp China Sale PE Plastic Pipe Production Line Single Screw Extruder PVC / PP / PE Pipe Extrusion Machine nhà cung cấp China Sale PE Plastic Pipe Production Line Single Screw Extruder PVC / PP / PE Pipe Extrusion Machine nhà cung cấp

Hình ảnh lớn :  China Sale PE Plastic Pipe Production Line Single Screw Extruder PVC / PP / PE Pipe Extrusion Machine

Thông tin chi tiết sản phẩm:

Place of Origin: ShanDong China
Hàng hiệu: AORUI
Chứng nhận: CE & ISO9001
Model Number: SJ65/33

Thanh toán:

Minimum Order Quantity: 1 set
Giá bán: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 30 sets per quarter
Contact Now
Chi tiết sản phẩm
Model Number: SJ65/33 Material: Stainless steel
After-sales service: Engineers availiable to service Inverter: ABB
Warranty: 12 months Chứng nhận: CE & ISO9001
Trademark: AORUI Place of original: Shandong , China

China Sale PE Plastic Pipe Production Line , Water Suppling PVC / PP / PE Pipe Extrusion Machine



Quick detail



1. Special single screw extruder for polyolefin , having high extruding velocity and effective plasticization. Separation mixing screw specialized for polyolefin. Specially designed 2-3 co-extruding die,  reasonbable channel , smooth outside and inside wall , and little internal stress. Producing pipe limit 20-160mm , manufacture velocity up to 15m/min. May be used to produce HDPE silicon core tube , Ordinary PP-R , PE , PEX and PE-RT pipes.



2. Equipment List:
1. SJ65x33 Single Screw Extruder
2. Extrusion Mould
3. Vacuum Calibrating Tank
4. Cooling Tank
5. Haul-off Machine(Tractor)
6. Cutting Machine
7. Stacker or Winder
8. Automatic Feeder and Dryer







Description:



1. PE / PPR pipes are used to build hot and cold water systems,including central heating systems. Building heating system,including floor,wall and radiant heating systems. Drinking water supply systems. In the central (concentration) air - conditioning systems.



2. The main machine adopts screws specially used for polyolefin. It possesses features of high production, good plasticization and stable extruding.



It is equipped with automatic vacuum appending machines and automatic constant temperature drying hopper.



3. Die heads of helical type and basket type are perfect for polyolefin, and can help to produce sound melting pressure, and improve the plasticization capacity. Meanwhile, stable material-flow and pressure grade can be guaranteed.



Advanced vacuum calibrating method improves the cleanliness and hardness of surface. Reasonable high-speed sprinkling cooling water tank guarantees the pipe quality and high speed stable extruding.



4. Caterpillar of the hauling machine adopts anti-abrasion alloy material, which realizes stable traction, wide frequency adjustment range and long lifespan.



New generation auto dust-free cutting blade realizes smooth cutting surface, high precision and low noise







Main technical parameter of HDPE pipe production line/ PE Pipe extrusion line

Item SJGF75 SJGF160 SJGF250 SJGF450 SJGF630 SJGF800 SJGF1000 SJGF1200 SJGF1600

Diameter

(mm)

20-75 63-160 75-250 160-450 315-450 400-800 500-1000 630-1200 1000-1600
Main machine

SJ25/25

SJ65/33

SJ25/25

SJ65/33

SJ25/25

SJ75/33

SJ25/25

SJ90/33

SJ25/25

SJ120/33

SJ150/33 SJ150/33

SJ90/33

SJ120/33

SJ120/33

SJ120/33

Max. capacity

(kg/h)

120-150 120-300 280-400 500-700 700-900 900-1200 900-1200 900-1400 1000-1700

Total power

(KW)

110 130 260 400 500 600 600 900 1000

If you want more details of our HDPE pipe machine/ HDPE pipe making machine, please let us know!







Application:



It is mainly used to produce PE water pipe, gas pipe, drain pipe and so on. This set is also suitable for the production of crosslinked PE pipes and other olefine products. Our company can provide you with detailed ingredients and complete manufacture line.





Why choose us:



1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.



China Sale PE Plastic Pipe Production Line Single Screw Extruder PVC / PP / PE Pipe Extrusion Machine
