PVC Drainage Pipe Plastic Extrusion Machinery , PVC Conical Twin Screw Extruder Machine

chất lượng tốt Dây chuyền đùn ống nhựa giảm giá
chất lượng tốt Dây chuyền đùn ống nhựa giảm giá
This machine is very good , and the after-saes service is good. The pvc board machine is easy to operate and the output is stable

—— Nancy

The pvc board extrusion machine is good quality , it is beautiful and the output is stable , this is a reliable company

—— Albert

Tôi trò chuyện trực tuyến bây giờ

PVC Drainage Pipe Plastic Extrusion Machinery , PVC Conical Twin Screw Extruder Machine

Trung Quốc PVC Drainage Pipe Plastic Extrusion Machinery , PVC Conical Twin Screw Extruder Machine nhà cung cấp

Hình ảnh lớn :  PVC Drainage Pipe Plastic Extrusion Machinery , PVC Conical Twin Screw Extruder Machine

Thông tin chi tiết sản phẩm:

Place of Origin: ShanDong China
Hàng hiệu: AORUI
Chứng nhận: CE UL CSA
Model Number: SJSZ65

Thanh toán:

Minimum Order Quantity: 1 set
Giá bán: Negotiable
Packaging Details: Fumigationwood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per month
Contact Now
Chi tiết sản phẩm
Plastic Processed: PVC Screw Design: double screw
Application: Pipe Condition: New
Inverter: ABB After-sales Service Provided: Engineers available to service machinery overseas
Place of Origin: Shandong , China (Mainland)

PVC Plastic Drainage Pipe Extrusion Machinery , PVC Conical Twin Screw Production Line





Quick detail:



1 . output:60-700kg/h

2 . pipe diameter:16-800mm

3 . ISO&CE standard

4 . test before delivery









Description:



The working process of PVC conduit pipe making machine:



PVC powder + additive → mixing → spring feeding → twin screw extruder → mould and calibrator → vacuum forming machine → haul off machine → cutting machine → discharging rack

1. It is a high-tech enterprise which is specialized in research, manufacture and marketing plastic extrusion lines,plastic production line.

2.Our plastic extrusion lines based on Plastic Extruders:Single Screw Extruder,Conical Twin Screw Extruder and Parallel Twin Screw Extruder.

3.Our plastic making machine can make many kinds of plastic productions like:PVC pipe,CPVC pipe,PE/HDPE/PE-RT pipe,PP-R pipe,plastic foamed profile,WPC profile and panel,wood plastic composite and so on.

4.Plastic Extuder is widely used in Plastic industry.It is the main part of Plastic Pipe Extrusion Line, Plastic Profile Extrusion Line,Plastic Recycling Line and Plastic Granulating Line.

5.We provide plastic machine which can make Agriculture pipe,machines to produce pellet,laminating machine,wooden window frames machine.

6.Our plastic extruder use good quality screw in plastic machinery.Our plastic machine have long-life.



Specifications:



Main Technical Parameters

MODEL

PVCG-110

PVCG-160

PVCG-250

PVCG-315

PVCG-400

PVCG-630

MATCHED EXTRUDER

SJZ51/105

SJZ65/132

SJZ65/132

SJZ80/156

SJZ80/156

SJG92/188

OD RANGE(mm)

50-110

50-160

75- 250

110-315

200-400

315-630

LENGTH OF VACUUM

CALIBRATOR TANK(mm)

6000

6000

6000

6000

6000

6000

HAUL SPEED(m/min)

0.6-6

0.5-5

0.4-4

0.3-3

0.2-2.5

0.2-1.5

INSTALLED POWER(kw)

67

85

95

125

135

255

TOTAL LENGTH9(mm)

17000

18000

20000

20500

28000

30000





Applications:



1 . It is mainly used to produce PVC conduit pipe.



2 . mould: change molds to produce different pipe products.



3 . After-sales Service Provided: Engineers available to service machinery overseas











Competitive Advantage:



1 . High-quality equipment and highly competitive market prices can bring you more profits.

2 . Good after-service , spare parts are free

3 . advanced technology and better quality
